DC14 Elite

separatore onda

capitulate

Material
UV ray ageing high resistance white neopentilic gelcoat. Handmade stratification with different mats placed and pressured separately by using high mechanical performance steel rolls and resins.
Bottom and sides made of plastic reinforced by incorporated fibreglass with cross and longitudinal reinforcements made of the same material and foam core. Motor blocks and floors made of sea-plywood coated with plastic reinforced by incorporated fibreglass. Deck made of laminated plastic reinforced by incorporated fibreglass, with mats, with “termanto” sandwich and screwing and reinforcements parts made of sea-plywood.
There are no contraindications, as to osmosis, for the hull made of plastic reinforced by incorporated fibreglass to stay underwater.

Hull and deck equipment
Peak for chain of m 75 and 8 mm diameter, fenders, CQR-DELTA type anchor, stainless steel pillar, 1000W winch with foot-control, fore sundeck, tempered crystal windows with baked varnish aluminium frame, electric windscreen wipers with stainless steel arms and washers with fresh water, no. 4 stainless steel bollards, no. 2 stainless steel fairleads, no. 1 gas oil embark point, no. 1 water embark point, stainless steel grab rod, stainless steel deck, aluminium saddle tank and PVC profile, primer and anti-vegetation, navigation lights, aluminium 2-shutter door to get the saloon, structural cockpit benches with peaks, hatches to get the stern peak and the engine room, cockpit lighting, bathing platform with hot and cold shower, pull-out stainless steel bath ladder, 220V socket, stainless steel and teak hydraulic gangway, teak-covered cockpit floor and bathing platform, 50-mm shafting.

Bridge
Steering position, wood-bordered steering wheel, flap remote control, switches: winch, navigations light washers, bilge pumps, instruments with light, gas oil and water-level electric indicators. Electronic instruments: echo-sounder, gps plotter, radar, vhf radio telephone. Magnetic compass, electronic control levers, engine/s boards.

Saloon
Floor with moquette, halogen lights with glass protection, curtains, wooden furniture, fabric or skay sofa, second dinette (on request), wooden dinner table and small table, no. 2 loudspeakers, steering position, electric boards, stairs to the night-time area, skay (or similar material) ceiling, skay and wooden side walls, clock and barometer, no. 1 fridge.

Kitchen
Sink, fridge, no. 1 24/220V socket, hot/warm water mixer, halogen spotlights, various shelves and drawers. In DC 14 the kitchen floor is lower than the saloon (on request).

Shipowner’s fore cabin
Double bed with chest of drawers, mattress, pillows and bedcover, two bedhead spotlights, wardrobe, various drawers and spaces, lights, moquette, bedhead mirror, curtains, no. 2 stainless steel portholes, walk-way with shading device, access to private bathroom, no. 1 24/220V socket, wooden doors, ceiling and walls covered with wood and skay.

Guest cabin (1)
Wardrobe, various drawers, no. 2 twin beds placed side by side, mattresses, pillows and bedcovers, porthole, moquette, no. 2 lights for reading, curtain, no. 1 24/220V socket, door.

Guest cabin (2)
Wardrobe, various drawers, no. 1 double bed near the wall, mattress, pillows and bedcover, no. 1 stainless steel porthole, moquette, no. 1 light for reading, wardrobe, various drawers, curtain, no. 1 24/220V socket, door.

Shipowner’s fore cabin - Bathroom
Direct access to the cabin, electric ceramic toilet bowl discharging into the sea, no. 1 washbasin, shower box, porthole with curtain, soap dish, glass holder, towel stand, clothes hook, 24/220V socket.

Guest cabins - Bathroom
Access to the corridor, electric ceramic toilet bowl discharging into the sea, no. 1 washbasin with pull-out shower-mixer, soap dish, glass holder, towel stand, clothes hook, 24/220V socket.

Engine room and peak
Hatch to enter the cockpit, engine gas exhausting system, no. 2 sea water plugs with 2 filters, steering wheels, 4-blade screws, battery slot, battery charger slot, 30 l 220 V boiler, autoclave, generator, gas oil pre-filters.

Electric equipment
Steering board and for rooms next to the steering position, anodic protection for all metallic parts subject to galvanic corrosion, mass system, 24/220V sockets in all the rooms, electric cables only with anti-fire sheath, electric board for rooms with magnetothermic switches, no. 1 voltmeter with rooms/engines commutator, alternator ammeter with rooms/engines commutator, no. 1 battery charger DC ammeter, no. 1 consumption absorption DC ammeter, 220V AC voltmeter, no. 2 engine starting keys, no. 2 engine starting buttons, no. 4 engine stop buttons, no. 2 flap control buttons, no. 2 winch control buttons, no. 2 instrument lights switches, no. 2 windscreen wiper lights switches, no. 1 windscreen wiper button, no. 3 bilge pumps manual control switches, shower pump manual control switch, no. 2 horn control switches, boat consumption led synoptic panel, no. 3 battery stoppers, 55A battery charger, no. 2 220 Ah engine start batteries, no. 2 200 Ah batteries for supply in rooms, generator battery, 220V AC 50A dock socket in the cockpit with 10-m cable, 30 mA differential magnetothermic switch.

Water system
Water tank, 24V autoclave, warm and cold water system in all bathrooms and kitchen, 220V electric boiler, tank with automatic discharging of grey water, three-way presetting for wc discharging.

Bilge system
No. 3 electropumps, connected to the rooms batteries, that can be operated automatically and manually by means of switches/lights in the steering rooms panel.

Seaman’s central cabin
Access to the kitchen by door or curtain, various shelves and drawers, single bed, manual wc, washbasin, no. 1 porthole with curtain.

Equipment and main accessories
Electric hard top , hydraulic steering compartment, no. 2 stainless steel tanks with settler cock, 5 Mase generator, hydraulic gangway, fore screw, tarpaulins kit, helm angle indicator, meter counter, gps plotter and multifunction 8,4” echo-sounder with fly repeater, radar, autopilot with fly second station, 250W inverter, air conditioning, black water tank, safety equipment for 6 people including: life raft, life jackets, no. 1 round life buoy with floating rope and light buoy without pile, no. 1 box of signal rockets, watch, barometer, medicine box, radar reflector, boat hook, Italian flag, powder extinguishers, no. 6 fenders with rope.

X


technical features

Materials:

PRFV

Weight:

19 t.

Bottom:

Dellapasqua

Beds:

n° 6 on 3 cabins +2
n° 1 bed for seaman +wc

EC length:

14,99 mt.

People capacity:

n° 16

Width:

4,40 mt

Fuel tank:

1700 lt

Motorization:

EC homologazione 1218 Hp 2 eb turbo diesel

Water tank:

400 lt





EC class:

B

X


Video

video
X

The total and complete customization makes Dellapasqua one of the few boatyards to design and build tailor-made boats, making them unique and guaranteeing a constructive quality studied right down to the smallest detail.

The DC 14 Elite is a boat brimming with personality, flaunting bold dynamic lines that also have a timelessly sober elegance. Its interiors offer complete comfort and its many possibilities for personalisation mean that every boat is unique. The lay-out is made to express personality with a slender line. The big hard top is electric and when it is open allows the entrance of air and light as it were an Open boat.
